Danfoss UQM Electric Motor + UQM Motor Controller Set

Motor Part No: 20080-038REM*A

SPM286-149-2

Serial No: 100022

System Specifications

Operating speed: 0-6000 rpm

Maximum / continuous power: 220 kW / 150 kW

Maximum / continuous torque: 700 Nm / 440 Nm

Peak efficiency: 94%

Operating voltage: 250-440 VDC

Communication: CAN bus

Specifications

Peak power: 295 hp 220 kW

Continuous power: 201 hp 150 kW

Peak torque: 516 lbf ft 700 Nm

Continuous torque: 325 lbf ft 440 Nm

Maximum efficiency: 94%

Continuous Power density: .87 hp/lb 1.5 kW/kg

ASSEMBLED IN USA

--------------------------------------------------

Motor Controller Part No: 1000T-012

Serial No: 1000T-012*B2*DV1168

Operating Voltage

Operating voltage input range: 250-440 VDC

Minimum voltage: 250 VDC

Nominal input voltage: 360 VDC

Maximum voltage: 440 VDC

DC current limitation, motoring: 500 A

Digital Signal Processor

Nominal input voltage: 12 VDC or 24 VDC

Input supply voltage range: 9 to 35 VDC

Input supply current range: 1 to 5 A

Liquid Cooling System

Minimum coolant flow: 10 l/min 50/50 water/glycol

Maximum inlet temperature: 140° F 60° C

Inverter Type

Control type: PWM & phase advance

Power device: IGBT

Switching frequency: 3 to 12 kHz

Standby power: 14 W

ASSEMBLED IN USA
